AUWELD MIG 220D MIG/MMA WELDING MACHINE 1PH/220V
Category: WeldingWelding & Cutting Machine
Specifications
Welding Process
MIG (GMAW), MMA (SMAW), LIFT TIG
Input Power Voltage (V)
AC220V±15%
Rated Input Current
6.1 kVA (MIG), 5.4 kVA (MMA), 3.3 kVA (LIFT TIG)
Output Current Range
20 - 200A (MIG), 20 - 160A (MMA), 20 - 160A (LIFT TIG)
No-Load Voltage (V)
52
Duty Cycle (%)
60
No Load Consumption
60
Efficiency (%)
85
Power Factor
0.93
Protection Class
IP21S
Insulation Class
F
Wire Reel (mm)
300
Weight
12.1 kg
Dimension (mm)
520 x 240 x 360
Warranty
1 Year
SKU
A2133220001
Details
Features:
- Automatic Overload Protection Function; prevent machine from damage if the duty cycle is exceeded or air flow is blocked.
- Deep welding pool, beautiful welding seam
- Integrated wired feeder and power
- Smooth and spatter-free start
- User-friendly, high welding speed
- Voltage control
- Simple-to-Use Operator Interface
- Industrial Application : Maintenance Repair, Metal Fabrication
Include Item(s):
- 1 pc 15AK MIG Torch (3m)
- 1 pc Welding Cable with Earth Clamp (2m)
- 2 pcs Cable Connector
Pictures are for illustration purposes only, actual may vary. Specifications are subject to change without prior notice.
