AUWELD MAX 120 PLASMA CUTTING MACHINE 3PH/415V

Category: Welding Welding & Cutting Machine

Specifications

Welding Process

MMA (SMAW), CUT

Input Power Voltage (V)

Three Phase, AC380V±15%

Rated Input Power

15.2 kVA (CUT), 9 kVA (MMA)

Rated Input Current

23.0 A (CUT), 13.7 A (MMA)

Output Current Range

20 - 100 A (CUT), 20 - 240 (MMA)

No-Load Voltage (V)

304 V (CUT), 67.5 (MMA)

Rated Output Voltage

120 V (CUT), 29.6 V (MMA)

Pre-gas Time

CUT: 0.1 - 5.0s, MMA: 0 - 80s (Arc start current)

Post-gas Time

CUT: 0 - 30s, MMA: 0 - 80s (Arc end current)

Duty Cycle (%)

Efficiency (%)

Power Factor

0.93

Protection Class

IP21S

Insulation Class

Arc Striking Method

Non-Striking

Air Pressure (MPa)

0.4

Weight

51.5 kg

Dimension (mm)

622 x 310 x 480

Suggested Cutting Thickness

25 mm

Cutting Thickness

40 mm

SKU

A2135120013

Plasma Cutting Machine Penang Welding Machine Supplier Penang Welding Machine Malaysia Auweld Plasma Cutting Machine Malaysia

Details

Features:

Automatic Overload Protection Function; prevent machine from damage if the duty cycle is exceeded or air flow is blocked
Deep welding pool, beautiful welding seam
Integrated wired feeder and powe
Smooth and spatter-free start
User-friendly, high welding speed
Voltage control
Simple-to-Use Operator Interface
Industrial Application : Maintenance Repair, Metal Fabrication, Shipyard, Oil & Gas

Include Item(s):

1 pc PT80 Plasma Torch (5m)
1 pc Welding Cable with Earth Clamp (2m)
1 pc Air Filter
2 pcs 35mm Cable Connector
1 pc Power Cable (2m)

Pictures are for illustration purposes only, actual may vary. Specifications are subject to change without prior notice.
